Four-post car liftFour-post car liftFour-post car liftFour-post car liftFour-post car liftFour-post car liftFour-post car liftFour-post car liftFour-post car lift

Four-post car lift

  • Product name   :

    Four post car lift

  • Model  :

    SJD

  • Drive model   :

    Hydraulic

  • Loading capacity   :

    4000kg--5000kg

  • Lifting height   :

    1900mm

  • Width between platform size   :

    1000mm

  • Power   :

    2.2kw

WhatsApp: +8618769790513
E-mail: info@morallift.com

MORAL LIFT can supply kinds of 4 Post alignment lift with Electric releas and Manual releas.loading capacity4000kg--5000kg.Come with Rolling jacks and Side Slipping plate.

The double lock system is automatically activated as the lift is raised. There is no need for the operator to go to both columns and manually unlock both column locks. All lifting and lowering operations are controlled from one column post. Double safety locks built into each column operated by one release level . Two locks...one release...available only in MORAL LIFT.

  • Loading capacity:4000kg and 5000kg.other loading capacity can be customized

  • Lifting height:1900mm.

  • Sec. Lifting Height: 350mm,Lifting time:50s

  • Distance Between Post: 2716mm,Width Between Platforms: 1000mm

  • Width of Each Platforms: 508mm,Length of Platform: 5000mm

  • Overall Length: 6130mm,Overall Width: 3276mm

  • Ramp length:880mm,Ramp width: 490mm
